OCL: |
Bioráin 1-7 = 1.45mH Min. @100KHz/1V |
LK: |
Bioráin 1-7(gearr 8-11.11-14)= 10.5uH Uasmhéid 100KHz 1V |
Bioráin 1-7(gearr 8-14)= 7.2uH Uasmhéid 100KHz 1V |
|
Cóimheas Casadh: |
28:6:6 ±3%. @20KHz/1.0V |
DCR: |
1-7: 68mΩ Uas. |
8-14: 8mΩ Uas. |
|
Hi-POT : |
N1-N2: 3750V AC/3mA/ 60S. |
N1-CORE: 3750V AC/3mA/60S. |
|
N2/N3 - CORE: 500V AC/3mA/60S. |
|
IR: |
N1-N2: 100MΩ Íosta DC500V |
COIL-CORE: 100MΩ Min DC500V |
